Event Trailer
Project Type:
Vehicle:
Use:
Client:
Custom Renovation
20' 1966 Overlander
Commercial
TailGate Group
This trailer had a 2 second appearance in a super bowl commercial! See it here and watch at the 17-19 second mark. Don’t blink!
This build was to be the showcase of the fleet, with all the amenities one could desire, wrapped in the vintage skin of a custom-restored Airstream!
For this build, the trailer had to be completely dismantled. We started with a 26’ trailer and built it to a 20’ tandem axle trailer from the donor parts. The client’s specification required that the trailer be able to fit into 2 parking spaces, along with a 10’ custom gullwing hatch to run the length of the trailer. The only original parts that remained were the front and rear endcaps and most of the ribs. The first order of business was to build a new frame. It needed heavy duty reinforcement in order to support the added weight of the large fresh, gray, and black water tanks that were needed. We also added new wheel wells, axles, and all the extras.
In the front end cap, we built a media center and display case that housed multiple TVs that are able to be seen from different angles. We installed a flawless transmission that ensured state-of-the-art audio/visual components and satellite inputs. The bathroom we built houses a simple toilet and vanity that was set up for comfort and convenience. Lastly, the exterior removable bar was built to fit.
Renovation:
-
Custom built frame 20’
-
Extra large holding tanks
-
Custom built shell
-
10' Gull Wing Serving Door
-
Tandem axles
-
Polished
-
Custom cabinetry
-
Custom shiplap walls
-
New vinyl flooring
-
Bathroom
-
White wall tires
-
All-New Wheel Wells, Axles, Shocks, and Tires
-
Custom Hand-Pieced Exterior Skin from Original
-
Custom service Bar
-
Custom Built Front Endcap Entertainment Center and Display Case
-
3 Satellite Hook Ups
-
Complete Audio/Visual Package
-
Custom Interior Bar with Ice Basin and Bar Sink
-
60" TV Mounted on Ship-lap Style Support Wall
-
32" TV Mounted Within Front Window
-
42" TV Mounted to Entertainment Center
